8131 Ultra-thin plate weighing force sensor
Range: 1kg/2kg/3kg/5kg/10kg/20kg/30kg
Body material: stainless steel
Comprehensive accuracy: 0.1%
Cable length: 0.2m
The 8131 is an ultra-thin plate weighing load cell with high precision and easy installation. It is often used for small-scale force or weight measurement, mechanical testing machines, electronic portable scales, and mechanical test models.
|
Specifications |
技术指标/Technique |
|
Capacity |
1, 2, 3, 5, 10, 20, 30kg |
|
Accuracy class |
0.1%F.S. |
|
Rated output |
1.5±0.1mV/V |
|
Zero balance |
±0.05 mV/V |
|
Non-linearity |
0.1%F.S. |
|
Hysteresis |
0.1%F.S. |
|
Repeatability |
0.05%F.S. |
|
Creep(30min) |
0.05%F.S. |
|
Temp.effect on output |
0.05%F.S./10℃ |
|
Temp.effect on zero |
0.05%F.S./10℃ |
|
Input impedance |
405±20Ω |
|
Output impedance |
350±10Ω |
|
Insulation |
≥5000MΩ/100VDC |
|
Recommended excitation |
5~15V |
|
Operation temp range |
-10~50℃ |
|
Safe overload |
150%F.S. |
|
Cable size |
4-Φ1×200mm |
|
IP Class |
IP65 |
